Sürücü Çalışma Modları
- Pozisyon Kontrol Modu (PP)
- Speed Kontrol Modu (PV)
- Tork Kontrol Modu (TQ)
- Homing Modu (HM)
- Cycle Synchronous Position Modu (CSP)
- Cycle Synchronous Speed Modu (CSV)
- Cycle Synchronous Torque Modu (CST)
Input ve Output Girişler
- 750 W üzeri 5 Dijital Input 3 Dijital Output
- 750 W ve altı 3 Dijital Input 3 Dijital Output
- Analog Input yok
- Line Driver Output yok
Haberleşme Fonksiyonları
- EtherCAT haberleşme portu
220 VAC Motor Uyumluluk Tablosu
| ÜRÜN KODU | GÜÇ | UYUMLU MOTOR |
|---|---|---|
| DS5C1-20P1-PTA | 100 W | MS6H-40CS30B1-20P1, MS6H-40CS30BZ1-20P1, MS6H-40CM30B1-20P1, MS6H-40CM30BZ1-20P1 |
| DS5C1-20P2-PTA | 200 W | MS6H-60CS30B1-20P2, MS6H-60CS30BZ1-20P2, MS6H-60CM30B1-20P2, MS6H-60CM30BZ1-20P2 |
| DS5C1-20P4-PTA | 400 W | MS6H-60CS30B1-20P4, MS6H-60CS30BZ1-20P4, MS6H-60CM30B1-20P4, MS6H-60CM30BZ1-20P4 |
| DS5C1-20P7-PTA | 750 W | MS6S-80CS20B1-20P7, MS6S-80CS20BZ1-20P7, MS6S-80CS30B1-20P7, MS6S-80CS30BZ1-20P7, MS6S-80CM20B1-20P7, MS6S-80CM20BZ1-20P7, MS6S-80CM30B1-20P7, MS6S-80CM30B1-20P7 |
| DS5C1-21P5-PTA | 1,5 kW | MS6S-100CS30B2-21P5, MS6H-130CS20B2-21P5, MS6H-130CS20BZ2-21P5, MS6S-100CM30B2-21P5, MS6H-130CM20B2-21P5, MS6H-130CM20BZ2-21P5 |
| DS5C1-22P3-PTA | 2,3 kW | MS6H-130CS15B2-22P3, MS6H-130CS15BZ2-22P3, MS6H-130CM15B2-22P3, MS6H-130CM15BZ2-22P3 |
| DS5C1-22P6-PTA | 2,6 kW | MS5G-130ST-CS10025B-22P6, MS5G-130ST-CS10025BZ-22P6, MS5G-130ST-CM10025B-22P6, MS5G-130ST-CM10025BZ-22P6 |
380 VAC Motor Uyumluluk Tablosu
| ÜRÜN KODU | GÜÇ | UYUMLU MOTOR |
|---|---|---|
| DS5C1-43P3-PTA | 3,3 kW | MS6H-180CS15B2-43P0, MS6H-180CS15BZ2-43P0, MS6H-180CM15B2-43P0, MS6H-180CM15BZ2-43P0 |
| DS5C1-44P4-PTA | 4,4 kW | MS6H-180CS15B2-44P4, MS6H-180CS15BZ2-44P4, MS6H-180CM15B2-44P4, MS6H-180CM15BZ2-44P4 |
| DS5C1-45P5-PTA | 5,5 kW | MS6H-180CS15B2-45P5, MS6H-180CS15BZ2-45P5, MS6H-180CM15B2-45P5, MS6H-180CM15BZ2-45P5 |
| DS5C1-47P5-PTA | 7,5 kW | MS6S-180CS15B2-47P5, MS6S-180CS15BZ2-47P5, MS6S-180CS15B2-47P5, MS6S-180CS15BZ2-47P5 |
| DS5C1-411P0-PTA | 11 kW | MS-220STE-TL70015B-411P0 |
| DS5C1-415P0-PTA | 15 kW | MS-220STE-TL96015B-415P0 |
